High Tension 1670mpa Plain Surface PC Steel Wire
Plain PC Wire
Low Relaxation Plain PC Wire
The plain PC wire can be supplied in different diameters: 5mm, 7mm and 9mm. It features good fixed performance, high tensile strength and low relaxation.
Specification
Material: high carbon steel (SWRH 82B/77B).Diameter: 3 mm - 12 mm.
Low Relaxation Plain PC Wire
· Diameter: 3 mm - 12 mm.
· Surface: smooth.
· Tensile strength: 1470 Mpa, 1570 Mpa, 1670 Mpa, 1770 Mpa, 1860 Mpa.
· Standards: BS 5896, BS5 892, GB/T 5223-2002, ASTM A421, ASTM A468, ASTM A911, ASTM A881/A881M, ISO 6934, ISO 6932, JIS G 3536, UNE 36094, etc.
|
Item |
Nominal diameter (mm) |
Tolerance (mm) |
Cross-sectional area (mm2) |
Mass per meter (g/m) |
|
PC-300 |
3.00 |
±0.04 |
7.07 |
55.5 |
|
PC-400 |
4.00 |
12.57 |
98.6 |
|
|
PC-500 |
5.00 |
±0.05 |
19.63 |
154 |
|
PC-600 |
6.00 |
28.27 |
222 |
|
|
PC-625 |
6.25 |
30.68 |
241 |
|
|
PC-700 |
7.00 |
38.48 |
302 |
|
|
PC-800 |
8.00 |
±0.06 |
50.26 |
394 |
|
PC-900 |
9.00 |
63.622 |
499 |
|
|
PC-1000 |
10.00 |
78.54 |
616 |
|
|
PC-1200 |
12.00 |
113.1 |
888 |
· Good fixed performance.
· High tensile strength and low relaxation.
· Steel wire cross-section area without any loss.
Application
· PC structures: plain PC strand, PC water pipes.
· Road and bridge structures: highways, bridges, airports, railway sleepers, tunnels.
· Building construction: industrial and civil prefabricated concrete slabs, frame of roofs, wall boards.
